Measurement range – axial length
14 – 38 mm
Measurement range – corneal radii
5 – 11 mm
Measurement range – anterior chamber depth
0.7 – 8 mm
Measurement range – lens thickness
1 – 10 mm (phakic eye) · 0.13 – 2.5 mm (pseudophakic eye)
Measurement range – central corneal thickness
0.2 – 1.2 mm
Measurement range – white-to-white
8 – 16 mm
Display scaling
Axial length / corneal radii / ACD / lens thickness 0.01 mm · central corneal thickness 1 µm · white-to-white 0.1 mm
SD of repeatability – axial length and cornea
Axial length 5 µm · Corneal radii 0.09 D · Cylinder > 0.75 D, axis 3.8°
SD of repeatability – anterior segment
Anterior chamber depth 7 µm · Lens thickness 6 µm · Central corneal thickness 2.5 µm · White-to-white 111 µm
IOL calculation formulas
Barrett Suite · Haigis Suite (Haigis, Haigis-L, Haigis-T) · Hoffer® Q · Holladay 1 and 2 · SRK®/T
Interfaces
ZEISS EQ Workplace · ZEISS FORUM · CALLISTO eye (via USB & FORUM) · EMR/PMS data interface · Ethernet port
Line voltage / frequency
100 – 240 V ± 10 %, 50 – 60 Hz
Power consumption
max. 150 VA
Specifications taken from the ZEISS product brochure. Configuration options may vary — contact AMK for a detailed proposal.
