Imaging modes
True Color (Red, Green, Blue channel split) · Fluorescein Angiography · Autofluorescence-Green/-Blue · Stereo
Additional imaging modes
Infrared reflectance · external eye image (ocular surface)
Field of view (from centre of the eye)
Widefield 133˚ (one image) · ultra-widefield 200˚ (two images) · montage up to 267˚ (up to six images)
Minimum pupil diameter
2.5 mm
Working distance
25 mm (patient’s eye to front lens)
Compensation for ametropia
- 24 D to + 20 D continuous
Light sources
Red LED 585 - 640 nm · Green LED 500 - 585 nm · Blue LED 435 - 500 nm · Infrared laser diode 785 nm
Acquisition speed
Live IR preview 10 frames/second · image capture ≤ 0.2 seconds
Automatic operations
Auto-focus · Auto-gain · Auto Montage · Auto-laterality
Instrument weight
50 lbs (22.7 kg)
Instrument dimensions (W x D x H)
15″ (38.1 cm) x 18″ (45.7 cm) x 27″ (68.6 cm)
Instrument table
Wheelchair accessible, electronic lift; 37″ (94 cm) x 27.5″ (70 cm); 81 lbs (37 kg)
Instrument input power
100-240VAC, 50/60 Hz · IEC 60601-1 Class I
Specifications taken from the ZEISS product brochure. Configuration options may vary — contact AMK for a detailed proposal.
