Type
ArF excimer laser, wavelength 193 nm (laser class 4 according to IEC 60825-1:2014)
Laser frequency
FLEXIQUENCE® 250 Hz / 500 Hz
Fixation laser
Solid-state laser, 532 nm (laser class 1 according to IEC 60825-1:2014)
Beam dimensions (spot scanning)
0.7 mm FWHM (full width at half maximum), Gaussian beam profile
PRESBYOND Laser Blended Vision
1.5 D anisometropia
Phototherapeutic keratectomy
Area ablation, PTK shaping
Active eye tracker
Infrared, pupil and limbus tracking, 1050 frames per second (fps), automatic Pupil Center Shift Correction
Surgical microscope
OPMI® pico with integrated HD video camera
Illumination
Ring illumination: stepless adjustment; sectional light; satellite illumination; optional slit lamp illumination
CCA+ (plume removal system)
Integrated into the device, automatic adaptation for 250 Hz / 500 Hz operation
Gas supply
Integrated ArF-Premix cylinder 10 l
Weight
295 kg with gas cylinder · patient support system 232 kg
Dimensions (W x D x H)
1.63 m × 0.73 m × 1.48 m – 1.70 m
Power supply
100 V AC; 50/60 Hz; 17.5 A · 120 V AC; 50/60 Hz; 14.6 A · 208, 220, 230, 240 V AC; 50/60 Hz; 7.9 A
Specifications taken from the ZEISS product brochure. Configuration options may vary — contact AMK for a detailed proposal.
